7 Pitch
Our 7-Pitch Roof double door garage features loft storage and is perfect for vehicles, or a workshop. The steeper roof on our double door garage design allows for extra head room for loft storage.
7 Pitch Double Wide Garage Features
- 4 X 4 Pressure Treated Foundation Runners
- 2 X 4 8′ ‘OC Floor joist with 3/4″ T&G Smart Finish Wood Flooring OR
- Pressure Treated 6 X 6 Perimeter with Steel Corner Reinforcements when ordered with No Floor
- 2 X 4 Wall Studs 16″ OC
- 8′ Walls
- Hurricane Ties Securing Rafters to Wall
- 1/2″ Painted Smartside Wood Siding or (Optional) Cedar Creek Vinyl Siding with ½” Wood Sheeting
- 2- Solid Steel Garage Doors (8 X 7 on 20′ Wide & 9 X 7 on 24′ Wide)
- 36″ Insulated House Door with 11-Lite Glass
- 4 – 24″ X 36″ Sliding Windows with Screens
- 4 – Pr Shutters
- 2 X 6 Rafters 24″ OC
- 7-Pitch Roof
- 1/2″ Wood Sheating on Roof
- 15 Lbs Tar Paper
- 30 Yr Architectural Shingles
- 2 – 4′ X 12′ Lofts on Back

View Additional Photos & Videos
Gallery7 Pitch Double Wide Garage Prices
Prices shown are meant to be a guide and don’t include delivery or custom features. Once you find your size, click “Get A Quote” and fill out the form to submit your ideas to a project manager, who will reach out to you with a full quote!
Size | Wood | Vinyl & LP Board & Batten | Hardie Plank |
20 X 20 | $16,280 | $19,540 | $21,980 |
20 X 24 | $18,115 | $21,740 | $24,460 |
20 X 28 | $19,835 | $23,800 | $26,780 |
24 X 24 | $19,870 | $23,840 | $26,820 |
24 X 28 | $21,745 | $26,090 | $29,360 |
24 X 32 | $23,460 | $28,150 | $31,670 |
24 X 36 | $25,535 | $30,640 | $34,470 |
24 X 40 | $27,825 | $33,390 | $37,560 |
24 X 42 | $29,200 | $35,040 | $39,420 |
24 X 44 | $30,320 | $36,380 | $40,930 |
24 X 46 | $31,935 | $38,320 | $43,110 |
24 X 48 | $32,960 | $39,550 | $44,500 |
24 X 50 | $34,695 | $41,630 | $46,840 |
24 X 52 | $35,785 | $42,940 | $48,310 |
24 X 54 | $37,480 | $44,980 | $50,600 |
24 X 56 | $38,555 | $46,270 | $52,050 |
7 Pitch Double Wide Garage Options
Paint / Shingle Colors for 7 Pitch Double Wide Garage
Paint Colors
Vinyl Colors
Aluminum Trim Colors
Metal Roofing Colors
Shingle Colors
